  2. 3 Amp Power Supply with (4) Fused Outputs (2 Amp) 12/24 3 Amp max with 4 ECB output fused at 2A max
Cypress Price Group 3

3 Amp Power Supply with (4) Fused Outputs (2 Amp) 12/24 3 Amp max with 4 ECB output fused at 2A max

https://mysecurity.odoo.com/web/image/product.template/111706/image_1920?unique=0f5d84c
(0 review)

Camden's affordable and high quality CX-PS300UL power supply features power protection, latching fire alarm outputs, selectable 12/24 VDC operation, battery charging and rugged metal cabinets.

    This combination does not exist.

    Contact Us

    Terms and Conditions

    • Latching fire alarm tie-in with reset
    • 12 or 24 VDC selectable outputs
    • AC power and status indicators
    • Short circuit and terminal protection
    • Battery charger (1.5 Amp)
    • 120/240 VAC power input
    • Low battery, battery disconnect, and battery charger trouble monitoring
    • Metal enclosure accommodates (2) 12Ah. batteries (not included)
    • CX-PS300UL:  (4) outputs, 3 Amp max
    • CX-PS600UL:  (8) outputs, 6 Amp max
    Output Power:
    (4) 3 Amps, 1.5 Amp Battery Charger
    Output Protection:
    Short Circuit Protection
    Battery Charger Monitor:
    		 Battery Load Test Every 48 Hour
    Voltage:
    		120/240 VAC
    Output Voltage:
    		12/24 VDC
    Enclosure Accommodates:
    		(2) 12 VDC / 12 Ah Batteries

    Dimensions:

    17-1/2"H x 13"W x 4-5/16"D (445 x 330 x 110mm)


    Spec Sheets
    CM-4000-5000-7000-8000_Spec Sheet_R4pdf0.59
    CM-8000-8100_Spec Sheet_R1pdf0.51
    Manuals
    CM-7085-8085_Manualpdf0.60
    CM-8000-8100_Manualpdf0.43​
