Features
- Heavy zinc plated steel construction
- Chrome plated latch bolt with Delrin insert for smooth, quiet latching
- 1⁄2″ (12.7 mm) latch throw
- Zinc alloy dead locking pin
- Left or right handed, field reversible
- Cylinder backset: 3 31⁄32″ (24.6 mm) or 1 1⁄8″ (28.6 mm)
- Lock accepts standard 1 5⁄32″ (29.4 mm) diameter mortise cylinder with cam A (Adams Rite type)
- Key or turnbutton controlled latch dogging
- Radius anodized aluminum or duronodic faceplate included
Documentation
Product Page
Instructions
DL2400 – Installation Instructions
Disclaimer
- We recommend that physical hardware be ordered and verified before starting any preparation, manufacturing or installation work.
- All product installations must be done by qualified personnel using the proper mounting hardware for the appropriate surface or material.
- We recommend that installers and manufacturers use the instructions inside the packaging provided by the manufacturer, as the manufacturer reserves the right to make technical changes, modify product or information without prior notice.
- Do not exceed the maximum weight or dimensions recommended by the manufacturer.
- All technical documents, drawings and instructions are provided as-is. Customers (primary or secondary) cannot derive any claim based on the use of these documents. No responsibility is or will be assumed
