Camden 3 amp power supply
CX-PS300UL
Camden's affordable and high quality CX-PS30UL and CX-PS60UL power supplies feature power protection, latching fire alarm outputs, selectable 12/24 VDC operation, battery charging and rugged metal cabinets.
FEATURES
- Latching fire alarm tie-in with reset
- 12 or 24 VDC selectable outputs
- AC power and status indicators
- Short circuit and terminal protection
- Battery charger (1.5 Amp)
- 120/240 VAC power input
- Low battery, battery disconnect, and battery charger trouble monitoring
- Metal enclosure accommodates (2) 12Ah. batteries (not included)
- CX-PS300UL: (4) outputs, 3 Amp max
- CX-PS600UL: (8) outputs, 6 Amp max
SPECIFICATIONS
|
| ||
|
Output Protection:
|
| ||
|
Battery Charger Monitor: |
Battery Load Test Every 48 Hour
| ||
|
Voltage:
|
120/240 VAC
| ||
|
Output Voltage:
|
12/24 VDC
| ||
|
Enclosure Accommodates:
|
(2) 12 VDC / 12 Ah Batteries
| ||
Dimensions:
|
17-1/2"H x 13"W x 4-5/16"D (445 x 330 x 110mm)
|
