Camera

• Image Sensor  1/3" Progressive Scan CMOS
• Max. Resolution  2560 × 1440
• Min. Illumination  Color: 0.001 Lux @(F1.0, AGC ON), B/W: 0 Lux with white light
• Shutter Speed  1/3 s to 1/100, 000 s
• Day & Night  24 Colorful imaging
• Angle Adjustment  Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°

Lens

• Lens Type  Fixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV

  2.8 mm, horizontal FOV 96.5°, vertical FOV 50.8°, diagonal FOV 113.9°

  4 mm, horizontal FOV 75.8°, vertical FOV 40.8°, diagonal FOV 89.1°

• Lens Mount  M12
• Iris Type  Fixed
• Aperture  F1.0

DORI

• DORI

  2.8 mm, D: 64.0 m, O: 25.4 m, R: 12.8 m, I: 6.4 m

  4 mm, D: 77.4 m, O: 30.7m, R: 15.5m, I: 7.7 m

• Supplement Light Type  White light
• Supplement Light Range  Up to 50 m
• Smart Supplement Light  Yes

Video

• Main Stream

  50 Hz: 20 fps (2560 × 1440)

  25 fps (1920 × 1080, 1280 × 720)

  60 Hz: 20 fps (2560 × 1440)

  30 fps (1920 × 1080, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

  60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

• Video Compression

  Main stream: .265+/.264+/H.265/H.264

  Sub-stream: H.265/H.264/MJPEG

• Video Bit Rate  32 Kbps to 8 Mbps
• H.264 Type  Baseline Profile/Main Profile/High Profile
• H.265 Type  Main Profile
• Region Of Interest (ROI)  1 fixed region for main stream

Network

• Protocols  TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
• Simultaneous Live View  Up to 6 channels
• API  Open Network Video Interface, ISAPI
• User/Host  Up to 32 users. 3 levels: administrator, operator and user
• Client  iVMS-4200, Hik-Connect
• Web Browser

  Plug-in required live view: IE 10+

  Plug-in free live view: Chrome 57.0+, Firefox 52.0+

  Local service: Chrome 57.0+, Firefox 52.0+

• Image Settings  Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser.
• Day/Night Switch  Day, Night, Auto, Schedule
• Wide Dynamic Range (WDR)  120 dB
• Image Enhancement  BLC, 3D DNR

Interface

• Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port

Event

• Basic Event  Motion detection, video tampering alarm, exception
• Linkage  Upload to FTP, notify surveillance center, send email, trigger capture

General

• Power

  12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug

  PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W

• Camera Material  Front cover: metal, body: plastic, bracket: metal
• Camera Dimension  83.7 mm × 80.7 mm × 206.6 mm (3.3" × 3.2" × 8.1")
• Package Dimension  260 mm × 125 mm × 125 mm (10.2" × 4.9" × 4.9")
• Camera Weight  Approx. 410 g (0.9 lb.)
• With Package Weight  Approx. 644 g (1.4 lb.)
• Storage Conditions  -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
• Startup And Operating Conditions  -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
• Language  English, Ukrainian
• General Function  Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

Approval

• EMC

  FCC-SDoC: 47 CFR Part 15, Subpart B

  CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014;

  RCM: AS/NZS CISPR 32: 2015;

  KC: KN 32: 2015, KN 35: 2015

• Safety

  CB: IEC 62368-1: 2014+A11;

  CE-LVD: EN 62368-1: 2014/A11: 2017

• Environment

  CE-RoHS: 2011/65/EU;

  WEEE: 2012/19/EU;

  Reach: Regulation (EC) No 1907/2006

• Protection  IP67: IEC 60529-2013
