  2. IDIS DC-U6K31WRA 5M 4-Channel AI Multi-Directional Camera, 3.3-7.02mm Motorized Varifocal Lens, IP67, IK10

IDIS DC-U6K31WRA 5M 4-Channel AI Multi-Directional Camera, 3.3-7.02mm Motorized Varifocal Lens, IP67, IK10

DC-U6K31WRA

https://mysecurity.odoo.com/web/image/product.template/161695/image_1920?unique=36b8325

This combination does not exist.

​

Contact Us

Terms and Conditions

Product Overview

The IDIS DC-U6K31WRA is an enterprise-grade 20MP (4 x 5MP) AI multi-directional network camera engineered for wide-area surveillance without blind spots. Featuring four independent 1/2.8" CMOS sensors with motorized varifocal lenses (3.3–7.02mm), it delivers comprehensive, multi-angle coverage from a single mounting point — reducing infrastructure costs while maximizing situational awareness. Built-in IDIS Deep Learning Analytics (IDLA) enables real-time AI-powered detection at the edge, while its rugged IP67 / IK10 housing ensures reliable performance in the harshest outdoor environments. NDAA & TAA compliant.

Key Features
  • ✓  4 x 5MP sensors — 20MP total resolution in a single unit
  • ✓  IDIS Deep Learning Analytics (IDLA) — edge AI for object detection & classification
  • ✓  3.3–7.02mm Motorized Varifocal Lens — remote focus & zoom per channel
  • ✓  120dB True WDR — outstanding performance in high-contrast scenes
  • ✓  IR Illumination up to 25m / 82ft — clear imaging in total darkness
  • ✓  IP67 & IK10 rated — weatherproof and vandal-resistant housing
  • ✓  H.265 + Intelligent Codec — up to 50% bandwidth savings
  • ✓  PoE IEEE 802.3at — single-cable power and data
  • ✓  DirectIP & ONVIF S/T — seamless NVR integration
  • ✓  NDAA & TAA Compliant — approved for government and federal projects
Specifications
Image Sensor4 x 1/2.8" Progressive Scan CMOS
Total Resolution20MP (4 x 2592 x 1944)
Lens3.3–7.02mm Motorized Varifocal (per channel)
Field of View96°H (wide) — 42.4°H (tele)
Pan / Tilt / Rotate0–360° / 0–80° / 0–90°
Minimum Illumination0.1 lux (color) / 0 lux (IR on)
IR Range25m / 82ft (3 IR LEDs per camera)
Dynamic Range120dB True WDR
Video CompressionH.265 / H.264 / Intelligent Codec
PowerPoE IEEE 802.3at Class 4 (21W)
Ingress ProtectionIP67 / NEMA4X
Impact ResistanceIK10
Operating Temperature-40°C to +55°C (-40°F to +131°F)
DimensionsØ258 x 112mm
Weight2.8kg / 6.2lb
ProtocolsONVIF Profile S/T, DirectIP
ComplianceNDAA Section 889, TAA Compliant

   DC-U6K31WRA_AnE_Spec_v1.0.0

  DC-U6K31WRA  Datasheet

  DC-U6K31WRA Installation Manual v1.0/

  DC-U6K31WRA Operation Manual v1.0

  DC-U6K31WRA Quick Guide v1.0
